FROM
6.400 Kg
CHASSIS
Galvanized
STEEL
High-Strength
Max. width 2,550 mm – Max. interior length 13,620 mm – Vehicle height 4,050 mm – Interior headroom (rear) 2,800 mm
Approx. total weight (±3%) 6,493 kg – Max. king pin weight (permissible/technical) 14,000/14,000 kg -- Max. axle group weight (permissible/technical) 24,000/27,000 kg – Max. total weight (permissible/technical) 38,000/41,000 kg Payload (permissible/technical) 31,507/34,507 kg
From 1050 to 1250
OUR GUIDELINES
- Hot-dip galvanized.
- High tensile steel construction.
- Reinforced chassis with heavy-duty bracing.
- Welded by robots with high precision.
- Lightweight Z-type crossbars, mounted at approximately 390 mm centre-to-centre, providing greater stability and strength. Rear crossbars (1,600 mm) mounted at 265 mm to reinforce the area where forklifts enter and exit the vehicle.
- 8,072 mm long coil cradles with 30⁰ angle downpipes. (Suitable for transporting reels between Ø 900 mm and Ø 2,000 mm net, including packaging).
- Approved in accordance with European standard DIN EN12642 XL and German standards VDI 2700 and DAIMLER 9.5 for a net load of 27,000 kg.
- Floor made of 30 mm thick 100% birch Finnish board (21 sheets), approved for the passage of a 8,100 kg forklift axle in accordance with ENV 1995-1-1.
- Side downpipes of the cradle made of 100% birch Finnish board, 28 mm thick.
- 16 cradle covers, 500 mm, made of 100% birch Finnish board, 30 mm thick, with metal reinforcements underneath. (cover weight < 27 kg)
- Front made of aluminum pillars with rounded corners for greater aerodynamics and horizontal slats clipped together and riveted to ensure greater strength.
- Reinforcement board on the inside of the front for greater safety.
- Aluminum rear doors with clipped and riveted profiles and double-action hinges.
